i-POOK PK8506 - network cable tester with multimeter function
The PK8506 offers a wide range of features including cable tracking, wire map testing, cable length testing, POE, electric circuit voltage / current / resistance measurement, and more.
-
Specifications Functions PK8506 PK8508 PK8509 Cable Length Network cable (600 m) /telephone line (400 m)
coaxial cable (400M)Digital Tracing √ √ √ Cable Mapping Normal /Open /Short /Cross QC crimping √ √ √ Flash 10M /100M /1000M POE Test Voltage /polarity Remote ID Optional functions ID 1~7 Accounting Function Storage record 100 /unit price /amount Special Function DMM x DMM x VFL VFL x OPM OPM Special Function Parameters Optical Power /OPM mW /uW /nW /-70.00~6.00 dBm Visual Fault Locator 10mW (~10 km) ON /1Hz /2Hz /OFF DMM Function 59999 count DC Voltage/DCV 600.00 mV ~ 1000 V (±0.5%+0.3) AC Voltage/ACV 600.00 mV ~ 750 V (±0.8%+0.5) DC Current/DCA 600.00 mA ~ 10 A (±1%+0.4) AC Current/ACA 600.00 mA ~ 10 A (±1%+0.5) Resistance/R 600.00 Ω ~ 60 MΩ (±1%+0.6) Capacitance/CAP 6.0000 nF ~ 60 MF (±2%+0.6) Frequency/Hz 6.0000 Hz ~ 6 MHz (±1%+0.1) Continuity Test < 10 Ω buzzer Diode Test/Diode √ Fuse Specification CE 5*20 mm 10A/1000V General specifications Other 3.2-inch 240*320 color screen, dual lithium battery, power supply, length self-calibration function, Power Specifications 1500 mAh (host) /800 mAh (receiver) / rechargeable lithium battery (with protection circuit)
Charging requires a 5V/2A/10W charger or above (not included)
Host: Charging time is about 2 hours, and the battery is fully charged and works for about 4 to 6 hoursPackage shell-shaped carrying bag /manual /tool kit /RJ45 cable /USB cable/ alligator clip cable /test lead (only for DMM) Package weight ~ 800 g Package size 25*16*7 cm
-
manufacturer i-POOKInventory VANItem number ipo-pk8506Weight 800 g/pcs
