i-POOK PK826B - Multifunctional cable locator

Inventory: VAN
i-POOK PK826B - Multifunctional cable locator
  • i-POOK PK826B - Multifunctional cable locator
74 000 Ft , (58 268 Ft+VAT)
shipping fee
:
Favourable delivery charges.
postage >
:
Domestic- 24h; international- 24-72h
pcs Add to Cart Add to Cart

Cable and pipe locator, multimeter and network cable tester in one device.
- Detection of electrical cables and pipes in walls and underground. Max. depth 2 m (depending on mode). Sensitivity adjustment, 6 transmission codes.
- Multimeter function: 60,000 digits, AC/DC voltage and AC/DC current measurement, continuity, diode test etc.
- Network cable test: wiring map (cross-connection, break, short circuit)

Details Data

  •

    Specifications
      PK826A PK826B
    Transmitter functions
     Output signal 124 kHz; CODE A/C/E/F/H/L; LEVEL 4
     External voltage detection DC 10~400 V ± 2%
    AC 10~400 V (50~400 Hz) ± 2%
     Display VA LCD; 320*240
     Flashlight √
     Power supply 1500 mAh Rechargeable lithium battery
     Fuse Cable Locator Fuse 2 A /500 V
    Multimeter, Network Cable Test
     Counts x (60000 count)
     DC Voltage x 6.0000 V ~ 1000 V (±0.5%+0.3)
     AC Voltage x 6.0000 V ~ 750 V (±0.8%+0.5)
     DC Current x 600.00 mA ~ 10 A (±1%+0.4)
     AC Current x 600.00 mA ~ 10 A (±1%+0.5)
     Resistance x 600.00 Q ~ 60 MQ (±1%+0.6)
     Capacitance x 6.0000 nF ~ 60 MF (±2%+0.6)
     Frequency x 6.0000 Hz ~6 MHZ (±1%+0.1)
     Continulty x < 10 Q
     Diode x √
     Wiremap x short, cross, break
     DMM fuse x CE 5*20 mm; 10 A / 1000 V
    Receiver functions
     Tracing depth The tracing depth depends of medium and application
     Cable locator mode approx. 0~2 m (single-pole application)
    approx. 0~0.5 m (double-pole application)
     NCV approx. 0~0.4 meters
     Display Signal Code /Level /Strength
     Flashlight √
     Power supply 1500 mAh rechargeable lithium battery
    Product
     Range (work) 0-40℃, max 80% RH (not condensation)
     Range (storage) -20~60℃, max 80% RH (not condensation)
     Charger requirements Charging requires a 5 V /2 A /10 W charger or above (not included)
     Size Transmitter:175*85*36 mm / Receiver:255*85*36 mm
    The package
     Package includes Color box /manual /tool kit /test lead /USB cable /Alligator clip cable  /Grounding pile Color box /manual /tool kit /test lead /USB cable /alligator clip cable/grounding pile /RJ45 cable /remote adapter
     Package size 30*21*8 cm 30*21*8 cm
     Package weight ~1280 g ~1280 g



  • manufacturer
    i-POOK
    Inventory
    VAN
    Item number
    ipo-pk826b
    Weight
    1.3 kg/pcs
