Huepar Y04CG - 16 lines, 4D (4x360°) compact green laser level, LCD display

Specifications:

• Laser Beam: Green Beam
• Projection: 16 Lines Green Laser Level
• Laser Class: Class 2 (IEC/EN60825-1/2014), < 1mW output
• Laser Wavelength: 505-535 nm
• Horizontal / Vertical Accuracy: ±3 mm / 10 m
• Leveling / Compensation Range: 3°±1°
• Leveling Time: ≤3 s
• Tilt mode
• Outdoor mode
• Working Distance (radius, 100 LUX) :≥15 m *

• Working Distance: ≥40 m with detector **
• Working Time: About 6 hours
• Power Source :3.7 V / 4000 mAh-lithium battery
• Charging Port:Type-C
• Charging Time:About 5 hrs
• Mount Size: 1/4''
• IP Rating: IP54

• Operating Temperature: -10℃ ~ +50℃
• Storage temperature: -20℃ ~ +70℃

* Depends on ambient light conditions.

** compatible with Huepar laser receviers: Huepar LR-6RG;  Huepar LR-5RG; Huepar LR-8RG; Huepar LR300

> LCD Angle Display: This 360-degree laser level is equipped with an advanced LCD display that conveniently and accurately displays the angles of the X-axis and Y-axis, ensuring that you can easily and accurately level or customize the desired angle, suitable for any DIY or professional project. Angle Reset to Zero: press and hold the "H" and "V" buttons and wait for 5 seconds. Class 2 (IEC/EN60825-1/2014)output power <1mW

> 2-3 Seconds Quick Leveling: With a rapid leveling feature, this tool quickly self-levels in just 2-3 seconds: Accidental drop of 40 inches will not affect the accuracy, and it can quickly return to the level in about 3 seconds after falling. Shaking during normal use can recover to the level in as fast as 2 seconds. saving you time and effort on the job. Whether you're working on construction sites or DIY projects at home, you can get straight to work without wasting precious time.

> Enhanced Laser Brightness for Clear Visibility/Pulse Mode: Equipped with upgraded laser brightness, this 3D lazer level tool can be used outdoors on a cloudy day or directly near a building during the day. Working range up to 98feet of accuracy within ±1/9 Inch at 33 Feet. The outdoor Pulse Mode allowing to extend the laser range up to 197 feet with Huepar laser detector LR-5RG/LR-6RG/LR-8RG/LR300

> Self Leveling / Manual Mode: Slide from locked to unlocked position to turn on self-leveling mode, the cross line laser will be automatically leveled within 4°, otherwise the 3D cross line laser will send out an alarm with the lasers blinking. Slide from unlocked to locked position or press and hold the brightness button for 3s to turn on/off the manual leveling mode, which can be placed at any angle of use.

> Selectable 4 x 360° Laser Lines for Full Layout: Huepar 4D laser level has four 360 planes of green laser light, can be individually selected with the H and V buttons. The top and bottom 360° horizontal lazer lines are ideal for installing ceilings and tiling. With the 360° L-shaped magnetic bracket, you can work more smoothly.

> Built-in Lithium Battery: The 3.7V/4000Amh built-in lithium battery can work continuously for 6 hours after being fully charged, which can meet the needs of a day's work. With the USB-C charging cable, you can work while charging without delaying the progress of the project.

Package Contents:

• 1 x Huepar Y04CG
• 1 x Type-C cord
• 1 x Magnetic Bracket
• 1 x User Manual
• 1 x Hard carry case

• Weight: 1.3 kg
• Size: 24x18x11 cm
